BCM5718 Programmer's Guide
Table 110: Generic VRQ Statistics (Offset 0x0BFF – 0x0A00) (Cont.)
VRQ# Statistics Name
IFHCOUTOCTETS
IFHCOUTUCAST
IFHCOUTMCAST
16
IFHCOUTBCAST
IFHCINOCTETS_GOOD
Reserved
IFHCINUCASTPKTS
IFHCINMULTICASTPKTS
Table 111: Default & Drop VRQ Statistics (Offset 0x09F7 – 0x09D0)
VRQ# Statistics Name
IFHCINOCTETS_GOOD
IFHCINOCTETS_BAD
IFHCINUCASTPKTS
0 (Default)
IFHCINMULTICASTPKTS
IFHCINBROADCASTPKTS
17 (Drop) IFHCINOCTETS_GOOD
Reserved
IFHCINUCASTPKTS
IFHCINMULTICASTPKTS
IFHCINBROADCASTPKTS

VRQ Filter Set Registers

The filter block may be programmed via the following set of registers:
• VRQ_FILT_ELEM_CFG_REG
• VRQ_FILT_ELEM_PTTRN_REG [0 through 31]: (Offset 0x5480–0x54FC)
• VRQ_FILT_SET_MASK_REG
Note: There is no equivalent of FILT_SET_CFG_REG(s) in VRQ-Filter Block. Also, Set#0 is non-
existent.
Broadcom
®
January 29, 2016 • 5718-PG108-R
Address Size
0x0BE0
0x0BE4
0x0BE8
0x0BEC
0x0BF0
0x0BF4
0x0BF8
0x0BFC
Address Size
0x09D0
0x09D4
0x09D8
0x09DC
0x09E0
0x09E4
0x09E8
0x09EC
0x09F0
0x09F4
[0 through 31]: (Offset 0x5400–0x547C)
[1 through 31]: (Offset 0x5504–0x557C)
VRQ Filter Set Registers
Description
32 Queue#16 Transmit
32 Queue#16 Transmit
32 Queue#16 Transmit
32 Queue#16 Transmit
32 VRQ#16 Receive
32 VRQ#16 Receive
32 VRQ#16 Receive
32 VRQ#16 Receive
Description
32 Default VRQ Stats (Receive)
32
32
32
32
32 Drop VRQ Stats (Receive)
32
32
32
32
Page 455
