BCM5718 Programmer's Guide
Table 99 depicts the implemented address regions of BAR4 and BAR5 in the BCM5718 family. Only two
structures are present: the MSI-X Table and the Pending Bit Array in the offsets shown in the table. Any host
accesses to the non-implemented addresses in these BARs must be gracefully handled by the controller; i.e.,
Reads return 0x0 and Writes have no effect whatsoever on the MAC.

Table 99: MSI-X Table and PBA Structures in BCM5718 Family

MSI-X Table DW3 Content
Entry# (32-bit)
N/A Reserved Bits [127:17]
Reserved Entry .............
16 Vec#16 Control
15 Vec#15 Control
...... ......
...... ......
4 Vec#4 Control
3 Vec#3 Control
2 Vec#2 Control
1 Vec#1 Control
0 Vec#0 Control
Broadcom
®
January 29, 2016 • 5718-PG108-R
DW2 Content DW1 Content
(32-bit) (32-bit)
(PBA)
............. .............
Msg#16 Data Msg#16 Addr H
Msg#15 Data Msg#15 Addr H
...... ......
...... ......
Msg#4 Data Msg#4 Addr H
Msg#3 Data Msg#3 Addr H
Msg#2 Data Msg#2 Addr H
Msg#1 Data Msg#1 Addr H
Msg#0 Data Msg#0 Addr H
DW0 Content BAR4 and BAR5
(32-bit) Offset
Pending Bits[16:0] 0x120
............. 0x110
Msg#16 Addr L 0x100
Msg#15 Addr L 0xF0
...... ......
...... ......
Msg#4 Addr L 0x40
Msg#3 Addr L 0x30
Msg#2 Addr L 0x20
Msg#1 Addr L 0x10
Msg#0 Addr L 0x00
MSI-X Plumbing
