BCM5718 Programmer's Guide
Name
Write DMA PCI FIFO Overrun
Attention Enable
Write DMA PCI Host Address
Overflow Error Attention
Enable
Write DMA PCI Parity Error
Attention Enable
Write DMA PCI Master Abort
Attention Enable
Write DMA PCI Target Abort
Attention Enable
Enable
Reset

Write DMA Status Register (offset: 0x4C04)

Name
Reserved
Write DMA Local Memory
Read Longer than DMA Length
Error
Write DMA PCI FIFO Overwrite
Error
Write DMA PCI FIFO Underrun
Error
Write DMA PCI FIFO Overrun
Error
Write DMA PCI Host Address
Overflow Error
Write DMA PCI Parity Error
Write DMA PCI Master Abort
Error
Write DMA PCI Target Abort
Error
Reserved
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
6 RW 0
5 RW 0
4 RW 0
3 RW 0
2 RW 0
1 RW 1
0 RW 0
Default
Bits Access Value
31:10 RO 0
9 W2C 0
8 W2C 0
7 W2C 0
6 W2C 0
5 W2C 0
4 W2C 0
3 W2C 0
2 W2C 0
1:0 RO 0
Description
Enable Write DMA PCI FIFO Overrun Attention.
Enable Write DMA PCI Host Address Overflow
Error Attention.
Enable Write DMA PCI Parity Error Attention.
Enable Write DMA PCI Master Abort Attention.
Enable Write DMA PCI Target Abort Attention.
This bit controls whether the Write DMA state
machine is active or not. When set to 0, it
completes the current operation and cleanly
halts. Until it is completely halted, it remains 1
when read.
When this bit is set to 1, the Write DMA state
machine is reset. This is a self-clearing bit.
Description
–
Write DMA Local Memory Read Longer Than
DMA Length Error.
Write DMA PCI FIFO Overwrite Error (PCI write
longer than DMA length).
Write DMA PCI FIFO Underrun Error.
Write DMA PCI FIFO Overrun Error.
Write DMA PCI Host Address Overflow Error.
Write DMA PCI Parity Error.
Write DMA PCI Master Abort Error.
Write DMA PCI Target Abort Error.
–
Write DMA Registers
Page 450
