Receive Rules Value/Mask Registers (offset: 0x484 + 8*N)

The BCM5718 family employs eight receive rules (N = 0 to 7).
Name
Mask/Value
Value

Receive Rules Configuration Register (offset: 0x500)

Name
Reserved
No Rules Matches Default
Class
Reserved
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
31:16 RW 0
15:0 RW 0
Default
Bits Access Value
31:6 RO 0
5:3 RW 0
2:0 RO 0
Ethernet MAC (EMAC) Registers
Description
For each bit set, the corresponding bit in the
value field is ignored during the rule match
process.
If bit 26 of the corresponding rule control register
is set, the field is used as an additional 16-bit
value for rule comparison.
This field specifies a 16-bit value for rule
comparison.
Description
–
Specifies the default class of service for the
frame if no rules are matched.
A value of 1 is the highest priority.
A value of zero will cause the frame to be
discarded.
–
Page 326
