Power Management Capability Register (offset: 0x48)

This register is reset by hard Reset.
Name Bits
PME Support 31:27
D2 Support 26
D1 Support 25
Aux Current 24:22
DSI 21
Reserved 20
PME Clock 19
Version 18:16
PM Next 15:8
Capabilities
PM Capability 7:0
ID

Power Management Control/Status Register (offset: 0x4C)

This register is reset by Hard Reset.
Name Bits Access
PM Data 31:24 RO
FW-RW
Reserved 23:16 RO
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Access Value Description
RO 0x08 if no Indicates the power states in which the device may assert
aux PME. A 0 for any bit indicates that the device is not capable of
asserting the PME pin signal while in that power state.
0x18 if aux
Bit 27: PME can be asserted from D0
Bit 28: PME can be asserted from D1
Bit 29: PME can be asserted from D2
Bit 30: PME can be asserted from D3H
Bit 31: PME can be asserted from D3C (default depends on
the presence of Aux power)
RO 0x0 Indicates whether the device supports the D2 PM state. This
device does not support D2; hardwired to 0
RO 0x0 Indicates whether the device supports the D1 PM state. This
device does not support D1
FW-RW
RO 0x0 This device supports the data register for reporting Aux
Current requirements so this field is N/A.
FW-RW
RO 0x0 Indicates that the device requires device specific initialization
(beyond PCI configuration header) before the generic class
device driver is able to use it. This device hardwires this bit to
0 indicating that DSI is not necessary
RO 0x0 –
RO 0x0 Indicates that the device relies on the presence of the PCI
clock for PME operation. This device does not require the PCI
clock to generate PME. Therefore, the bit is hardwired to 0
RO 0x3 A value of 011b indicates that this function complies with
revision 1.2 of the PCI PM specification.
RO 0x58 Points to the next capabilities block which is Broadcom Vendor
Specific Capability Header
RO 0x01 Identifies this item as Power management capabilities
Default
Value Description
0x00 Contains the power management data indicated by the Data
Select field in PMCSR
0x00 –
