BCM5718 Programmer's Guide
Name
TARGET_LINK_SPEED
SLOT_CAPABILITY_2 – 0xe0
Name
SLOT_CAPABILITY_2
SLOT_STATUS_CONTROL_2 – 0xe4
Name
SLOT_STATUS_2
SLOT_CONTROL_2

Product ASIC ID (offset: 0xF4)

Name
Product ASIC ID
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
3:0 RW 0x1
Default
Bits Access Value
31:0 RO 0
Default
Bits Access Value
31:16 RO 0
15:0 RO 0
Default
Bits Access Value
31:0 RO
Description
Upper limit of link speed
Path= i_cfg_func.i_cfg_public.i_cfg_exp_cap
Value Name Description
0 2_5 2.5 Gbps
1 5_0 5.0 Gbps
255 – end_of_table
Description
Not implemented
Description
Not implemented
Not implemented
Description
For 5717 B0, value is 0x05717100:
• 5718 A0, value is 0x05717000
• 5718 B0, value is 0x05717100
• 5719 A0, value is 0x05719000
• 5719 A1, value is 0x05719100
• 5720 AO, value is 0x05720000
PCI Configuration Registers
Page 300
