Broadcom NetXtreme/NetLink BCM5718 Series Programmer's Manual page 540

BCM5718 Programmer's Guide
Bit Name
7 AUTONEG
RESOLUTION ERROR
6:5 LINK PARTNER
REMOTE FAULT
4 AUTONEG PAGE
RECEIVED
3 CURRENT OPERATING
DUPLEX MODE
2 SERDES LINK
1 PAUSE RESOLUTION–
RECEIVE SIDE
0 PAUSE RESOLUTION–
TRANSMIT SIDE
Broadcom
®
January 29, 2016 • 5718-PG108-R
RW Description
RO 1 = autoneg hcd is none (no common half or full
duplex abilities)
0 = SGMII mode, or autoneg disabled, or no
resolution error
RO 1000-X register 5 [13:12]
RO 1 = page has been received since last read
LH
0 = page has not been received since last read
RO 1 = phy is operating in full-duplex mode
0 = phy is operating in half-duplex mode (or
auto-negotiation has not completed)
RO 1 = link is up for SerDes applications
(SGMII or GBIC mode => both SerDes and
copper must have link for this bit to be set)
0 = link is down for SerDes applications
RO 1 = enable pause receive
0 = disable pause receive
RO 1 = enable pause transmit
0 = disable pause transmit
10h–1Fh Register Map Detailed Description
Default
0
00
0
0
0
0
0
Page 540
