The Ethernet controller can support up to eight message types, and these MSI messages can be generated by
either of the two sources of:
•

Host coalescing engine

•

Firmware

Host Coalescing Engine
After the host coalescing engine updates the status block on the host (due to receive indication, transmit
completion, and so on), it either generates an interrupt or writes a MSI message if MSI is enabled. The least
significant 3-bits of the MSI message originating from host coalescing block is configurable and can be
configured by programming bits 4, 5, and 6 of the Host_Coalesing_Mode register. The default of these bits is
zeros.
Firmware
The Ethernet controller provides a way for firmware executed by RX RISC to generate MSI messages. Firmware
can generate MSI messages by using MSI_FIFO_Access register (Offset 0x6008). For example, if firmware
wants to generate an MSI message with least significant 3-bit as 0x2, it will write 2 to MSI_FIFO_Access
register. It also needs to verify that the MSI message is written successfully by reading back MSI_FIFO_Access
Overflow. If this bit is zero, then the MSI message is encoded successfully and will be sent to HOST. Otherwise,
the message is not encoded.
Note: Without any special firmware supporting multiple MSIs, the device can generate only 1 MSI
message even though the device requests for 8 MSI messages through Multiple Message Capable
field (bits 3:1) of Message Control register (offset 0x5A). The least significant 3-bits of the MSI
message generated by the device are always taken from bits 6:4 of Host_Coalesing_Mode register
(offset 0x3C00).
