Tx Time Watchdog Lsb[1] Reg [Offset 0X6920]; Tx Time Watchdog Msb[1] Reg [Offset 0X6924]; Eav Ref-Count Snap-Shot Lsb[1] Reg [Offset 0X6930] - Broadcom NetXtreme/NetLink BCM5718 Series Programmer's Manual

BCM5718 Programmer's Guide
Name
Watchdog MSB Value

TX TIME WATCHDOG LSB[1] REG [Offset 0x6920]

Name
Watchdog LSB Value

TX TIME WATCHDOG MSB[1] REG [Offset 0x6924]

Name
Enable Lock Timer
Watchdog MSB Value

EAV REF-COUNT SNAP-SHOT LSB[1] REG [Offset 0X6930]

This LSB and MSB pair captures the EAV Reference Count when externally triggered by the desired TimeSync/
APE_GPIO pin – a toggle serves a trigger. The only legal sequence of accessing this pair is Read-LSB followed
by Read-MSB.
Name
EAV Reference Count
Snap-shot [lower half]
Broadcom
®
January 29, 2016 • 5718-PG108-R
Bits Access Default Value Description
30:0 RW 0x00
Bits Access Default Value Description
31:0 RW 0x0000
Bits Access Default Value Description
31 RW 0
30:0 RW 0x00
Bits Access Default Value Description
31:0 RO U
This, concatenated with the Watchdog[0] LSB value,
constitutes a 63-bit value. Precision of the value is
1ns – which equates to the precision of the EAV
Reference Count.
If bit[31] ==1, the desired TimeSync/APE_GPIO shall
toggle as soon as EAV Reference Count[62:0]
increments to match this 63-bit value.
Note: Setting this time value back in time will
produce no toggle.
See TX Time Watchdog MSB[1] Register
Write a 1 to enable Time Watchdog[0].
This, concatenated with the Watchdog[0] LSB value,
constitutes a 63-bit value. Precision of the value is
1ns – which equates to the precision of the EAV
Reference Count.
If bit[31] ==1, the desired TimeSync/APE_GPIO shall
toggle as soon as EAV Reference Count[62:0]
increments to match this 63-bit value.
Note: Setting this time value back in time will
produce no toggle.
LSB of the EAV Reference Count as snapshotted by
TimeSync/APE_GPIO [2:0] shall always be 000.
Time Sync Registers
Page 166
