Receive Data and Receive BD Initiator Control Registers

All registers reset are core reset unless specified.

Receive Data and Receive BD Initiator Mode Register (offset: 0x2400)

Name
Reserved
Legacy
Large RX Ring Sizes
Reserved
No BD Discard Policy
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
31:17 RO 0
31:14 0
16 RW 0
15 RO 0
14:13 RW 00
Receive Data and Receive BD Initiator Control Registers
Description
–
Defined by Legacy
When this bit is 1, following are the maximum
allowable Receive Ring sizes:
Standard Producer Ring == 2048
Jumbo Producer Ring
Receive Return Ring
When this bit is 0, following are the maximum
allowable Receive Ring sizes:
Standard Producer Ring == 512
Jumbo Producer Ring
Receive Return Ring
–
This field decides what to do with a packet in
RXMBUF belonging to a generic VRQ, when not
a single BD is available in the VRQ's BD Cache:
00 => The RDI shall discard an RX packet
belonging to a VRQ, if no corresponding RX BD
is available in the VRQ's BD Cache
01 => RDI shall place the RX packet in the
Default VRQ instead
10 => RDI shall wait for a BD to become
available in the VRQ's BD cache, no matter how
long it takes.
11 => Reserved for future use.
Ignored in non-IOV mode
== 1024
== 4096
== 256
== 1024
