BCM5718 Programmer's Guide
Table 103: High Priority Mail Box Registers for VRQ Rings (Cont.)
RX Jumbo
VRQ Ring Producer
# Index
1 0x2D4
2 0x2D8
3 0x2DC
4 0x2E0
5 0x2E4
6 0x2E8
7 0x2EC
8 0x2F0
9 0x2F4
10 0x2F8
11 0x2FC
12 0x340
13 0x344
14 0x348
15 0x34C
16 0x350
Additional Notes:
• 0x268 – 0x298, 0x88, 0x98 are legacy registers
• NIC Diagnostic Standard RBD Consumer Index [1 – 16] == 0x3F40–0x3F7C
• NIC Diagnostic Jumbo RBD Consumer Index [1 – 16] == 0x3F80–0x3FFC

Ethernet MAC (EMAC) Registers

All registers reset are core reset unless specified.
Broadcom
®
January 29, 2016 • 5718-PG108-R
RX Standard
Ring Producer RX Return Ring
Index Consumer Index Comments
0x354 0x288 (64-bit
Regs)
0x358 0x290 (64-bit
Regs)
0x35C 0x298 (64-bit
Regs)
0x360 0x2A0
0x364 0x2A4
0x368 0x2A8
0x36C 0x2AC
0x370 0x2B0
0x374 0x2B4
0x378 0x2B8
0x37C 0x2BC
0x380 0x2C0
0x384 0x2C4
0x388 0x2C8
0x38C 0x2CC
0x390 0x2D0
Ethernet MAC (EMAC) Registers
The new Registers are 32-bit
The new Registers are 32-bit
NIC Diagnostic
RX Return Ring
Producer Index
0x3C84
0x3C88
0x3C8C
0x3C90
0x3C94
0x3C98
0x3C9C
0x3CA0
0x3CA4
0x3CA8
0x3CAC
0x3CB0
0x3CB4
0x3CB8
0x3CBC
0x3CC4
Page 309
