Receive List Placement Statistics Control Register (offset: 0x2014)

Name
Reserved
Statistics Clear
Reserved
Statistics Enable
Receive List Placement Statistics Enable Mask Register (offset:
0x2018)
Name
Reserved
RSS_Priority
RC Return Ring Enable
CPU MACTQ Priority Disable 23
Reserved
Disable MACTQ Double Ack
issue fix
Reserved
Disable ASF Lockup Issue Fix 1
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
31:3 RO 0
2 RW 0
1 RO 0
0 RW 0
Default
Bits Access Value
31:26 RO 0
25 RW 0x0
24 RW 0x0
RW 0x0
22:19 RO 0
18 RW 1
17:2 RO N/A
RW 1
Receive List Placement Registers
Description
–
When set, resets local statistics counters to zero.
Clears only masked statistics.
Self-clearing when done.
–
When set, allow the local statistics counters to
increment.
When reset, counters hold their values until the
next update to the NIC memory.
Enables only masked statistics.
Description
–
This bit enables the receive packet to choose
receive return ring in terms of RSS hash value
instead of RC class when both RSS and RC rules
are matched. Default is to give priority to RC.
1: Enable receive packet to use RC rule class as
return ring number if RC rule is matched. This bit
will be used in conjunction with bit25 to derive the
final receive return ring.
0: Disable receive packet to use RC rule class as
return ring number. Receive packet only uses
RSS hash to select the receive return ring. If no
any RSS hash types are applied, the default ring
0 will be used.
1: Disable CPU priority over SDC when
arbitrating the MACTQ write requests.
0: Enable CPU priority over SDC when
arbitrating the MACTQ write requests.
–
Disable MACTQ double ack issue fix.
1: Disabled
0: Enabled
–
Disable ASF Lockup Fix.
1: Disabled
0: Enabled
