Name
EAV Reference Count
Snap-shot (lower half)

EAV Ref Count Snapshot MSB[0] Reg (offset: 0x6914)

Name
EAV Reference Count
Snap-shot (Upper half)

TX Time Watchdog LSB[0] Reg (offset: 0x6918)

Name
Watchdog LSB Value

TX Time Watchdog MSB[0] Reg (offset: 0x691C)

Name
Enable Lock Timer
Watchdog MSB Value

TX Time Watchdog LSB[1] Reg (offset: 0x6920)

Name
Watchdog LSB Value
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
31:0 RO U
Default
Bits Access Value
31:0 RO U
Default
Bits Access Value
31:0 RW 0x0000
Default
Bits Access Value
31 RW 0
30:0 RW 0x00
Default
Bits Access Value
31:0 RW 0x0000
Miscellaneous Control Registers
Description
LSB of the EAV Reference Count as snapshot by
Timesync/APE GPIO.
[2:0] shall always be 000
Description
MSB of the EAV Reference Count as snapshot by
TimeSync/APE GPIO.
Description
See "TX Time Watchdog MSB[0] Reg (offset:
0x691C)".
Description
Write a 1 to enable Time Watchdog[0].
This, concatenated with the Watchdog[0] LSB
value, constitutes a 63-bit value. Precision of the
value is 1ns–which equates to the precision of the
EAV Reference Count.
If bit[31] ==1, the desired Timesync/APE GPIO
shall toggle as soon as EAV Reference
Count[62:0] increments to match this 63-bit value.
Note: Setting this time value back in time will
produce no toggle.
Description
See "TX Time Watchdog MSB[1] Reg (offset:
0x6924)" on page 485.
Page 484
