BCM5718 Programmer's Guide

HTX2B Statistics

The HTX2B statistics reside in Transmit MAC. A counter is automatically reset to 0 by hardware upon a Read
Operation. All counters roll over.
Statistics Name
HTX2B Octets
HTX2B UCAST PKTS
HTX2B MCAST PKTS
HTX2B BCAST PKTS
HTX2B DROP PKTS
HTX2B DROP OCTETS

B2HRX Statistics

The B2HRX statistics reside in RDI.
Statistics Name
B2HRX OCTETS
B2HRX UCAST PKTS
B2HRX MCAST PKTS
B2HRX BCAST PKT
B2HRX DROP PKTS
B2HRX DROP OCTETS

Receive MAC Static Counters

ifHCInOctets (offset: 0x880)

The number of octets received on the interface, including frame characters.

ifHCINOctets_bad (offset: 0x884)

The number of bad octets received on the interface.

etherStatsFragments (offset: 0x888)

A frame size that is less than 64 bytes with a bad FCS.
Broadcom
®
January 29, 2016 • 5718-PG108-R
Set1 Set2
Address Address
0x700 0x720
0x704 0x724
0x708 0x728
0x70C 0x72C
0x710 0x730
0x714 0x734
Set1 Set2
Address Address
0x24D0 0x24E8
0x24D4 0x24EC
0x24D8 0x24F0
0x24DC 0x24F4
0x24E0 0x24F8
0x24E4 0x24FC
Size Description
32 Total number of H2B octets.
32 Number of H2B unicast frames.
32 Number of H2B multicast.
32 Number of H2B broadcast frames.
32 Number of H2B frames dropped by
EMAC.
32 Total number of H2B octets dropped by
EMAC.
Size Description
32 Total number of H2B octets.
32 Number of B2H unicast frames.
32 Number of B2H multicast frames.
32 Number of B2H broadcast frames.
32 Number of B2H frames dropped by
RDI.
32 Total number of B2H octets
dropped by RDI.
Statistics Registers
