Send Data Initiator Statistics Mask Register (Offset: 0Xc0C); Send Data Initiator Statistics Increment Mask Register (Offset: 0Xc10); Local Statistics Register (Offset: 0Xc80-0Xcdf) - Broadcom NetXtreme/NetLink BCM5718 Series Programmer's Manual

BCM5718 Programmer's Guide
Name
Zap Statistic
Flush Statistic
Statistics Clear
Faster Update
Statistics Enable

Send Data Initiator Statistics Mask Register (offset: 0xC0C)

Name
Reserved
Counters Enable Mask

Send Data Initiator Statistics Increment Mask Register (offset: 0xC10)

Name
Reserved
Counters Increment Mask
Reserved
Counters Increment Mask
Local Statistics Register (offset: 0xC80–0xCDF)
Name
Reserved
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
4 RW 0
3 RW 0
2 RW 0
1 RW 0
0 RW 0
Default
Bits Access Value
31:1 RO 0
0 RW 0
Default
Bits Access Value
31:24 RO 0
23:19 WO 0
18:16 RO 0
15:0 WO 0
Default
Bits Access Value
31:10 RO 0
Send Data Initiator Registers
Description
–
–
If set, resets local statistics counters to zero.
Clears only masked statistics.
Self-clearing when done.
–
When set, allows the local statistics counters to
increment. When reset, counters hold their
values until next update to NIC memory.
Enables only masked statistics.
Description
–
Controls whether Class of Service 0 statistics
can be updated, cleared, or flushed.
Description
–
Writing 1 to the bit position forces the
corresponding statistics counters to increment by
1. Not affected by Statistics Enable Mask.
Bits 16:23 correspond to Set Send Producer
Index, Status Updated, Interrupts, Avoided
Interrupts, Send Threshold Hit respectively.
–
Writing 1 to the bit position forces the
corresponding statistics counters to increment by
1. Not affected by Statistics Enable Mask.
Bits 15:0 correspond to statistics for Class of
Service 16:1
Description
–
Page 346
