BCM5718 Programmer's Guide
Name
MII Completion
Reserved
Link State Changed
Reserved

EMAC Event Enable Register (offset: 0x408)

Name
Reserved
Enable TX Offload Error
Interrupt
Interesting packet PME
Attention Enable
TX Statistics Overrun
RX Statistics Overrun
ODI Error
AP Error
MII Interrupt
MII Completion
Reserved
Link State Changed
Reserved
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
22 W2C 0
21:13 RO 0
12 RO 0
11:0 RO 0
Default
Bits Access Value
31:30 RO 0
29 RW 0
28 RW 0
27 RW 0
26 RW 0
25 RW 0
24 RW 0
23 RW 0
22 RW 0
21:13 RO 0
12 RW 0
11:0 RO 0
Ethernet MAC (EMAC) Registers
Description
Management interface transaction has
completed.
Generates an attention when enabled.
–
Set when the link state has changed
Generates an attention when enabled by bit 12 of
the EMAC Event Enable register.
Clear this attention by writing 1 to Sync Changed
(bit 4) and Config changed (bit 3).
–
Description
–
Enables or unmasks the interrupt associated
with Reg 0x404[29].
When this bit is set, an attention will be asserted
on an interesting packet match.
Enable attention when transmit statistics block
has overrun.
Enable attention when receive statistics block
has overrun.
Enable attention when an output data interface
block has an overrun or underrun.
Enable attention when the auto-polling interface
has an error.
Enable attention when the Management
Interface is signaling an interrupt.
Enable attention when the Management
Interface transaction has completed.
–
Enable attention when the link has changed
state.
–
Page 312
