1Fh: Test2_Register - Broadcom NetXtreme/NetLink BCM5718 Series Programmer's Manual

BCM5718 Programmer's Guide
Bit Name
12 FORCE LINK
11 FORCE LOCK
10 SCRAMBLER TEST
9 EXTERNAL LINK
8 FAST TIMERS
7 MANUAL SWAP MDI
STATE
6 RECEIVE WATCHDOG
TIMER DISABLE
5 DISABLE POLARITY
ENCODE
4 ENABLE SOFTWARE
TRIM SETTING (MAIN
DAC)
3:0 TRIM[3:0] (MAIN DAC)

1Fh: Test2_Register

Bit Name
15:13 TEST SELECT AUTONEG
FSM
12 TEST AUTO-NEG TIMER RW
Broadcom
®
January 29, 2016 • 5718-PG108-R
RW Description
RW 1 = force link state machine into pass state
0 = normal operation
RW 1 = force descrambler in to locked state
0 = normal operation
RW 1 = speed up descrambler unlock detect timer
0 = normal operation
RW 1 = use tpin11 input as link status
0 = normal operation
RW 1 = timers are sped up for LSI test
0 = normal operation
RW 1 = Swap
0 = off
RW 1 = watchdog timer disabled
0 = reset receive PMD when descrambler can't lock within
730us of link or lock loss.
RW 1 = disable 1000BASE-T polarity encoding
0 = normal operation
RW 1 = use software trim setting
0 = use hardware trim setting
Notes:
1) register settings from slice1, slice8 are used to control
main dac
2) register settings from slice2, slice7 are used to control
hybrid dac
RW Software trim setting
Notes:
1) only slice1, slice8 register setting are used.
2) Main dac value going to BIAS block (when enable
software trim setting = 0) is fuse_in(main
dac)+011(default)+software trim setting (main dac)
RW Description
RW 000 = ARB
001 = RX1000
010 = RX
011 = TX1000
100 = TX
101 = BASET LINK
1 = auto-negotiation timer test mode
0 = normal operation
10h–1Fh Register Map Detailed Description
Default
000
0
Default
0
0
0
0
0
0
0
0
0
0
Page 546
