BCM5718 Programmer's Guide

Global Mutex Grant Register (offset: 0x36F4)

Note: This register is for BCM5719/BCM5720 only.
This register is reset by POR Reset or CPMU Register Software Reset.
Name
Reserved
Set Request/Request Pending 7:0

Temperature Monitor Control Register (offset: 0x36FC)

Note: This register is for BCM5719 and BCM5720 only.
This register is reset by POR Reset or CPMU Register Software Reset. This register is shared by 4 MAC ports.
User must first gain grant from the global MUTEX registers (0x36F0 & 0x36F4) before writing to it.
Name
Reserved
Temperature Monitor Power
Down
Temperature Monitor Hold
Temperature Data
Bias Adjust
ADC Test Enable
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
31:8 DC 0
RW 1S 0x0
Default
Bits Access Value
31:19 RO 0
18 RW 0
17 RW 0
16:8 RO 0
7:1 RW 0
0 RW 1
Central Power Management Unit (CPMU) Registers
Description
–
Reading this field shall return a maximum of one
set bit at any time. The set bit shall point to the
lock owner. If the Mutex is not locked, a read
shall return a value 0x0000. Writing a 1 to the
already set bit shall relinquish the lock and the
set bit shall be cleared. Writing a 1 to an unset bit
shall cancel the corresponding pending request if
there was any–and the paring bit in the
Mutex_Request_Reg shall be cleared. Writing a
0 to any bits has no effect.
Description
–
Temperature Monitor Power Down
Temperature Monitor Hold
Temperature Data
Bias Adjust
ADC Test Enable
