Revision Levels; Table 3: Family Revision Levels - Broadcom NetXtreme/NetLink BCM5718 Series Programmer's Manual

BCM5718 Programmer's Guide
Feature
High-speed on-chip Application
Processor Engine (APE)
Wake-on-LAN (WOL)
Energy Efficient Ethernet (EEE)
Ethernet Audio Video (EAV)
Secure Digital (SD) Card Reader
IEEE 1588 / IEEE 802.1AS Timestamp
Support
On-chip temperature monitor
Integrated Trusted Platform Module
(TPM) Security Engine
Process voltage
CMOS linewidth

Revision Levels

See Table 3 for the revision levels of the Ethernet controllers covered by this document. Host software can use
the PCI Revision ID and Chip ID information in the PCI configuration registers to determine the revision level of
the Ethernet controller on the board, and then load the appropriate workaround described in the errata sheets.
The Broadcom PCI vendor ID is 0x14E4.
be modified by firmware in accordance with the manufacturing information supplied in NVRAM (see
Configuration" on page 67
Family Member Device ID
BCM5717 0x1655
BCM5717 0x1655
BCM5718 0x1656
BCM5718 0x1656
BCM5719 0x1657
BCM5719 0x1657
BCM5720 0X165F
a. See Device ID and Vendor ID Register (Offset: 0x00)—Function 0", per PCI specification.
b. See "PCI Classcode and Revision ID Register (offset: 0x8)—Function 0" as per the PCI specification. The
hardware default value of this register is 0x00. The boot code firmware programs this register with the value
as given in the table.
Broadcom
®
January 29, 2016 • 5718-PG108-R
Table 2: BCM5718 Family Product Features (Cont.)
BCM5717
Dual-Port
Copper
Yes
Yes
No
No
No
No
No
No
1.2V
65 nm
Table 3 shows the default values of PCI device IDs. These values may
for more details).

Table 3: Family Revision Levels

PCI Revision
Revisio
a b
n Level ID
A0 0x00
B0 0x10
A0 0x00
B0 0x10
A0 0x00
A1 0x01
A0 0x00
BCM5718 BCM5719
Dual-Port Quad-Port
Copper/SerDes Copper/SerDes
Yes Yes
Yes Yes
Yes Yes
No No
No No
No Yes
No Yes
No No
1.2V 1.2V
65 nm 65 nm
Product ASIC
c d
Chip ID ID
0xF000xxxx 0X5717000
0xF100xxxx 0X5717100
0xF000xxxx 0X5717000
0xF100xxxx 0X5717100
0xF000xxxx 0X5719000
0XF100XXXX 0X5719100
0xF000xxxx 0X5720000
Revision Levels
BCM5720
Dual-Port
Copper/SerDes
Yes
Yes
Yes
No
No
Yes
Yes
No
1.2V
65 nm
"NVRAM
e
Errata Sheet
5717-ES1xx-R
5717-ES1xx-R
5718-ES1xx-R
5718-ES1xx-R
5719-ES1xx-R
5719-ES1XX-R
5720-ES1xx-R
Page 49
