BCM5717 / BCM5718 Register Map

This is the Host Standard View of BAR1 and BAR2.
Block Name Block Range
HP Mail Box 0x0000–0x01FF
0x0200–0x03FF
EMAC 0x0400–0x07FF
EMAC STAT 0x0800–0x0BFF
SDI 0x0C00–0x0FFF
SDC 0x1000–0x13FF
SBDS 0x1400–0x17FF
SBDI 0x1800–0x1BFF
SBDC 0x1C00–0x1FFF
RQP 0x2000–0x23FF
RDI 0x2400–0x27FF
RDC 0x2800–0x2BFF
RBDI 0x2C00–0x2FFF
RBDC 0x3000–0x33FF
CMPU 0x3400–0x37FF
DBU 0x3800–0x3BFF
Broadcom
®
January 29, 2016 • 5718-PG108-R

Table 158: BCM5717 / BCM5718 Register Map

Sub-Block Range
0x0000–0x01FF
0x0200–0x03FF
0x0400–0x06FF
0x0700–0x7FF
0x0800–0x08FF
0x0900–0x09CF
0x09D0–0x0BFF
0x0C00–0x0CF7
0x0CF8–0x0FFF
0x1000–0x100B
0x100C–0x13FF
0x1400–0x147F
0x1480–0x17FF
0x1800–0x1847
0x1848–0x1BFF
0x1C00–0x1C03
0x1C04–0x1FFF
0x2000–0x2258
0x2259–0x23FF
0x2400–0x24C3
0x24C4–0x24FF
0x2500–0x27FF
0x2800–0x2803
0x2804–0x2BFF
0x2C00–0x2C1B
0x2C1C–0x2FFF
0x3000–0x300F
0x3010–0x33FF
0x3400–0x35FF
0x3600–0x3687
0x3800–0x3817
0x3900–0x3907
0x3908–0x3BFF
BCM5717 / BCM5718 Register Map
Description
Unused (Legacy–PCIe Configuration
Register Shadow)
High Priority Mail Boxes
EMAC
Unused
EMAC Statistics (Aggregated)
APE Private EMAC Stats (Aggregated)
IOV per Queue EMAC Statistics
Send Data Initiator
Unused
Send data Completion
Unused
SBDS Registers
Unused
Send BD Initiator
Unused
Send BD Completion
Unused
Receive List Placement
Unused
Receive Data Initiator
Unused
VRQ RCB Registers
Receive Data Completion
Unused
Receive BD Initiator
Unused
Receive BD Completion
Unused
Unused
Central Power Management Unit
Debug Unit (UART)
Chip Debug
Unused
