EEE Control Register (offset: 0x36D0)

Name
EEE Minimum Assert
EEE Exit Time

Current Measurement Control Register (offset: 0x36D4)

Name
Reserved
Freeze 2s Average
Freeze Count
Recalibrate
Current Measurement Read
Select
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
31:16 RW 0x0
15:0 RW 0x190
Default
Bits Access Value
31:5 RW 0x0
4 RW 0x0
3 RW 0x0
2 RW 0x0
1:0 RW 0x0
Central Power Management Unit (CPMU) Registers
Description
The minimum time from start of LPI message
transmission to end of LPI message
transmission.
Time from the end of LPI message transmission
to when normal transmission is allowed again.
Description
–
Stop the update of the 2 second average register.
The accumulation and holding registers will still
update.
Stop the accumulation process of the PDRIVE
samples. This effectively disables the cur_meas
block, and freezes all values of registers. This bit
can be set to stop the register updates for
register reads, and then restarted.
Restart the calibration process and capture a
single 500 µs accumulation period.
0x0: Current Measurement Upper 32-bit Read
Register = 0x0
Current Measurement Lower 32-bit Read
Register = 500 µs Calibration Count
0x1: Current Measurement Upper 32-bit Read
Register = 1s Hold Count[63:32]
Current Measurement Lower 32-bit Read
Register = 1s Hold Count[31:0]
0x2: Current Measurement Upper 32-bit Read
Register = 2s Hold Count[63:32]
Current Measurement Lower 32-bit Read
Register = 2s Hold Count[31:0]
0x3: Current Measurement Upper 32-bit Read
Register = 2s Average Count[63:32]
Current Measurement Lower 32-bit Read
Register = 2s Average Count [31:0
