Uncorrectable Error Severity Register (offset: 0x10C)

This register is reset by Hard Reset.
Name
Reserved
Unsupported Request Error
Severity
ECRC Error Severity
Malformed TLP Severity
Receiver Overflow Error
Severity
Unexpected completion Error
Severity
Completer Abort Error
Severity
Completion Timeout Error
Severity
Flow control Protocol Error
Severity
Poisoned TLP Severity
Reserved
Surprise down error severity
Data Link Protocol Error
Severity
Reserved
Training Error Severity
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
31:21 RO 0
20 RWS 0
19 RWS 0
18 RWS 1
17 RWS 1
16 RWS 0
15 RWS 0
14 RWS 0
13 RWS 1
12 RWS 0
11:4 RO 0
5 RO 1
4 RWS 1
3:1 RO 0
0 RWS 1
Description
–
This bit controls the severity
0 = nonfatal
1 = fatal
This bit controls the severity
0 = nonfatal
1 = fatal
This bit controls the severity
0 = nonfatal
1 = fatal
This bit controls the severity
0 = nonfatal
1 = fatal
This bit controls the severity
0 = nonfatal
1 = fatal
This bit controls the severity
0 = nonfatal
1 = fatal
This bit controls the severity
0 = nonfatal
1 = fatal
This bit controls the severity
0 = nonfatal
1 = fatal
This bit controls the severity
0 = nonfatal
1 = fatal
–
Pcie 1.1 spec page 409
This bit controls the severity
0 = nonfatal
1 = fatal
–
This bit controls the severity
0 = nonfatal
1 = fatal
PCI Configuration Registers
Page 303
