Broadcom NetXtreme/NetLink BCM5718 Series Programmer's Manual page 581

BCM5718 Programmer's Guide
Region
Unmapped
SBD Cache
(Relocated or
expanded in
BCM5717/BCM5718)
Std RBD Cache
(Relocated or
expanded in
BCM5717/BCM5718)
Jumbo RBD Cache
(Relocated or
expanded in
BCM5717/BCM5718)
TX MBUF
(Relocated or
expanded in
BCM5717/BCM5718)
Unmapped
C
RXCPU ROM
PCI Configuration
High Priority Mailbox
Functional Registers
Mailboxes
Scratch Pad
(Relocated or
expanded in
BCM5717/BCM5718)
Unmapped
RXCPU ROM Slave
Access
Send RCB0 NIC
Address
Receive Standard
Producer RCB0 NIC
Address
Broadcom
®
January 29, 2016 • 5718-PG108-R
Table 157: BCM5717 / BCM5718 Memory Map (Cont.)
Size NIC CPU View
32KB 0x0001A000-
0x0001FFFF
16KB 0x00020000-
0x00023FFF
17KB 0x00024000-
0x000283FF
17KB 0x00028400-
0x0002C7FF
29KB 0x0002C800-
0x00033BFF
15M 0x00033C00-
+817KB 0x00FFFFFF
1.2KB 0x40000000-
0x400004FF
256B 0xC0000000-
0xC00000FF
512B –
31KB 0xC0000400-
0xC0007FFF
1MB –
28KB 0xC0030000-
0xC0036FFF
4KB 0xC0037000-
0xC0037FFF
8KB 0xC0038000-
0xC009FFF
4B 0x00004000-
0x0000400F
4B 0x00040000-
0x0004000F
BCM5717 / BCM5718 Memory Map
Host Standard
Host Flat View View (Offset)
0x0101A000- 0x0001A000-
0x0101FFFF 0x0001FFFF
0x00020000- 0x00020000-
0x00023FFF 0x00023FFF
0x01024000- 0x00024000-
0x010283FF 0x000283FF
0x01028400- 0x00028400-
0x0102C7FF 0x0002C7FF
0x0102C800- 0x0002C800-
0x01033BFF 0x00033BFF
0x01033C00- 0x00033C00-
0x01FFFFFF 0x00FFFFFF
– –
0x00000000- 0x00000000-
0x000000FF 0x000000FF
0x00000200- 0x00000200-
0x000003FF 0x000003FF
0x00000400- 0x00000400-
0x00007FFF 0x00007FFF
0x00100000- –
0x001FFFFF
0xC0030000- 0xC0030000-
0xC0036FFF 0xC0036FFF
0xC0037000- 0xC0037000-
0xC0037FFF 0xC0037FFF
0xC0038000- 0xC0038000-
0xC0039FFF 0xC0039FFF
0x01004000- 0x00004000-
0x0100400F 0x0000400F
0x01040000- 0x00040000-
0x0104000F 0x0004000F
Host UNDI
View
0x0001A000-
0x0001FFFF
0x00020000-
0x00023FFF
0x00024000-
0x000283FF
0x00028400-
0x0002C7FF
0x0002C800-
0x00033BFF
0x00033C00-
0x00FFFFFF
–
0x00000000-
0x000000FF
0x00005800-
0x000059FF
0x00000100-
0x00007FFF
–
0xC0030000-
0xC0036FFF
0xC0037000-
0xC0037FFF
0xC0038000-
0xC0039FFF
0x00004000-
0x0000400F
0x00040000-
0x0004000F
Page 581
