BCM5718 Programmer's Guide

Send BD Initiator Control Registers

All registers reset are core reset unless specified.

Send BD Initiator Mode Register (offset: 0x1800)

Name
Reserved
Multiple Send Ring mode
Pass_bit status
Sbdi_rupd_enable
Attention Enable
Enable
Reset

Send BD Initiator Status Register (offset: 0x1804)

Name
Reserved
Error
Reserved
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
31.6
31:5 RO 0
5 RW 0
4:0
4 RW 0
3 RW 0
2 RW 0
1 RW 1
0 RW 0
Default
Bits Access Value
31:3 RO 0
2 RO 0
1:0 RO 0
Send BD Initiator Control Registers
Description
Unchanged
–
Write a 1 to enable 16 Send Rings.
Write a 0 to limit to a Single Send Ring.
Unchanged
Always return 1 when read.
–
When this bit is set to 1, an internal attention is
generated when an error occurs.
This bit controls whether the Send BD Initiator
state machine is active or not. When set to 0, it
completes the current operation and cleanly
halts.
Until it is completely halted, it remains 1 when
read.
When this is set to 1, the Send BD Initiator State
machine is reset.
This is a self clearing bit.
Description
–
Send BD Initiator Error.
–
Page 353
