Customer-Replaceable Units - Oracle X6-2 Service Manual

Callout Description
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21

Customer-Replaceable Units

The following table lists the customer-replaceable units (CRUs) in the server and directs you to
the replacement instructions.
CRU Description
Battery Lithium coin-cell battery that powers the CMOS BIOS
and real-time clock.
DIMMs Add or replace memory modules in the system.
Storage drives Supports SAS hard-disk drives (HHDs), SATA solid-
state drives (SSDs), and NVMe SSDs.
Internal USB flash Supports two internal USB flash drives.
drives
Super capacitor (Energy storage module for the Oracle Storage 12 Gb/s SAS PCIe RAID HBA in PCIe slot
4.)
Fan modules
Motherboard
Processors
Note - In single-processor systems, neither a heatsink nor a processor socket filler are installed in the
processor socket 1 (P1). To protect the delicate processor socket pins, the cover that comes on the
motherboard from manufacturing is left in place.
Heatsinks
Battery
USB flash drives
Air baffle
Top cover
(Optional) PCIe card in slot 3
Oracle Storage 12 Gb/s SAS PCIe RAID HBA card in PCIe slot 4
(Optional) PCIe card in slot 2
(Optional) Oracle PCIe NVMe switch card or standard PCIe card in slot 1
Note - PCIe slot 1 is nonfunctional in single-processor systems.
PCIe risers (3)
DIMMs
A maximum of 12 DIMMs are supported in single-processor systems and the DIMMs must be
Note -
installed in sockets associated with processor 0 (P0). No DIMM filler panels are required in vacant DIMM
sockets associated with processors 0 (P0) or 1 (P1).
Power supplies
Server chassis
(Optional) DVD drive
About System Components
Replacement Instructions
"Servicing the Battery (CRU)" on page 116
"Servicing the DIMMs (CRU)" on page 85
"Servicing Storage Drives (CRU)" on page 63
"Servicing the Internal USB Flash Drives
(CRU)" on page 113
About the Oracle Server X6-2 19
