Customer-Replaceable Units - Oracle X8-2L Service Manual

Figure Description
Legend
7 Motherboard assembly
8 Processors and heatsinks (Single-processor systems contain only a single processor in socket P0; socket P1
contains a cover to protect processor socket pins.)
9 Internal M.2 SATA flash SSDs
10 Top cover
11 (Optional) Oracle Storage 12 Gb SAS PCIe RAID HBA, Internal card and super capacitor
12 PCIe cards (PCIe slots 1 through 6 are nonfunctional in single-processor systems.)
13 System battery
14 (Optional) Internal USB drive
15 Power supplies
16 Air baffle
17 DIMMs (Only twelve DIMMs are supported in single-processor systems and the DIMMs must be installed
in P0 DIMM sockets.)

Customer-Replaceable Units

The following table lists the customer-replaceable units (CRUs) in the server and directs you to
the replacement instructions.
CRU Description
Battery Lithium coin-cell battery that powers the CMOS
BIOS and real-time clock.
Air baffle Aids in the cooling the system components.
DIMMs Add or replace memory modules in the system.
Storage drives Storage drive configurations can comprise both hard
disk drives (HDDs), solid state disk drives (SSDs),
or NVMe drives. Configurations include:
■ Up to twelve 3.5-inch hot-pluggable SAS3
■ Up to twelve 2.5-inch hot-pluggable PCIe-based
Internal HBA super Super capacitor and cable for the Oracle Storage 12
capacitor and super Gb SAS PCIe RAID HBA, Internal card
capacitor cable
Internal M.2 SATA Supports up to two hot-pluggable internal M.2
flash SSDs SATA flash SSDs.
HDDs/SSDs
NVMe SSDs
About System Components
Replacement Instructions
"Servicing the Battery
(CRU)" on page 141
"Servicing the Air Baffle
(CRU)" on page 113
"Servicing the DIMMs
(CRU)" on page 119
"Servicing Storage Drives
(CRU)" on page 69
"Servicing the Internal HBA Card
(FRU) and HBA Super Capacitor
(CRU)" on page 181
"Servicing the Internal M.2 Flash
SSDs (CRU)" on page 99
About the Oracle Server X8-2L 21
