Field
Pri
State
Type
VLAN Index
VRID
Sample IP VRRP Summary Display
Select menu option (ip/vrrp): summary
Enter VLAN interface index (2|?) [2]:
Enter virtual router ID (1|?) [1]:
VLAN Index: 2 Ports: 7-12,14
VRID Address
1 158.101.175.228
Description
Priority of the the virtual router. Represented by a value
from 0 through 255. Used in Master router election.
Value of 255 indicates that the router owns the IP
addresses that are associated with the virtual router. 0
indicates that the current Master has stopped
participating in VRRP.
Current state of the VRRP router. One of the following:
Master — In this state, the router is the active
forwarding router for all IP addresses that are
associated with the virtual router.
Backup — In this state, the router monitors the
availability of the Master router. If the Master router
fails, the Backup router assumes forwarding
responsibility for all IP addresses that are associated
with the virtual router.
Initialize — Transitional state between Backup
and Master states. Typically indicates that the virtual
router has been configured but not enabled, or that
the virtual router mode has been set to disabled.
In this state, the router waits for a Startup event.
When the router receives the Startup event, it
broadcasts an ARP request that contains the virtual
router MAC address for all IP addresses that are
associated with the virtual router and transitions to the
Master state. If the Startup event is not received, it
transitions to the Backup state.
Type of virtual router: primary or backup
Index number of the virtual LAN (VLAN) on which the
virtual router is defined
Virtual Router ID (0 – 255) . Must be unique on the LAN
Type State Interval
Primary Master 1 sec.
ip vrrp summary
Pri Preempt Auth
255 Yes pass
487
Error
none
