3Com SuperStack II 9300 Command Reference Manual page 480

C 16: I
480
HAPTER NTERNET
ip
advancedTraceRoute
3500
9000
9400
3900
9300
P (IP)
ROTOCOL
For CoreBuilder 9000: Applies to Layer 3 switching modules only.
Traces a route to a host with one or more of the advanced traceRoute
options.
Valid Minimum Abbreviation
ip advancedT
Important Considerations
When you specify a host name, the host name and its associated IP
address must be configured on a network name server. Also, you must
add the IP address on the name server to the list of name server
addresses that are associated with the network domain name. See "ip
dns domainName" earlier in this chapter for more information.
To interrupt the command, press Enter.
Options
Prompt Description
Host name or Host name or IP address of the
IP address destination that you want to ping.
Maximum ttl Maximum number of hops that the
system can use in outgoing probe
packets.
Destination Destination (or base) UDP port
port number that the system uses in probe
packets. Set the destination UDP port
number to be very high to ensure that
an application at the destination is
not using that port.
Probe count Maximum number of probes that the
system sends at each TTL level.
Wait Maximum amount of time that the
system waits for a response to a
probe.
Packet size Number of bytes that the system
sends in each UDP probe packet.
Source address Source address other than the one
from which the probe packets
originate. This option is available if
you have more than one IP interface
defined on the system .
Possible
Values [Default]
A valid host 0.0.0.0
name
IP address
1 – 255 hops 30
30000 – 33434
65535
1 – 10 3
1 – 10 seconds 3
28 – 4096 28
bytes
n (no) y
y (yes)
