3Com SuperStack II 9300 Command Reference Manual page 253

Field
bridgeHelloTime
bridgeIdentifier
bridgeMaxAge
designatedRoot
forwardDelay
gvrpState
(3500 and 9000 L3)
helloTime
holdTime
ipFragmentation
(3500 and 9000 L3)
ipxTranslation
(3500 and 9000 L3)
lowLatency
Description
Configurable time period in seconds that elapses between
configuration messages when the bridge is the root
bridge. (If the bridge is not the root bridge, the bridge
uses the value shown in the helloTime field which is
assigned to it by the root bridge.) The default value is 2
seconds. The acceptable range is 1 – 10 seconds. To
configure the bridge hello time, see "bridge spanningTree
stpHelloTime" later in this chapter.
Unique bridge identification that includes the bridge
priority value and the MAC address of port 1.
Configurable time period in seconds that the bridge uses
to discard the stored configuration message when it is
operating as the root bridge. (If the bridge is not the root
bridge, it uses the value shown in the maxAge field
instead which is assigned to it by the root bridge.) The
default value is 20 seconds. The acceptable range is 6 – 40
seconds. To configure the bridge maximum age, see
"bridge spanningTree stpMaxAge" later in this chapter.
Identity of the root bridge. It includes the root bridge's
priority value and the MAC address of port 1 on that
bridge.
Time period in seconds that the bridge spends in each of
two states — listening and learning — as assigned by the
root bridge. Compare with the bridgeFwdDelay field.
Status of GARP VLAN Registration Protocol (GVRP) for the
entire bridge. You configure GVRP as a bridge state as
well as individual port states. To configure GVRP for the
bridge, see "bridge gvrpState" later in this chapter. To
configure GVRP on ports, see "bridge port gvrpState" in
Chapter 10.
Time period in seconds that elapses between the
configuration messages that the bridge receives from the
root bridge. Compare with the bridgeHelloTime field.
Minimum delay time the bridge uses between topology
change BPDUs that it sends.
Shows configuration state of the IP fragmentation option.
The default setting is enabled. To configure this option,
see "bridge ipFragmentation" later in this chapter.
Shows configuration state of IPX SNAP translation. The
default setting is disabled. To configure this option, see
"bridge ipxSnapTranslation" later in this chapter.
(Not available at this release)
bridge display 253
