Image Density Sensor Assembly Removal - Lexmark X940e Service Manual

Replacement warning: Ensure that all PC cartridge units are properly seated and aligned before raising the
transfer belt lift handle to its upper-most position, or damage will occur. Never force the transfer belt lift handle
into its home position, or damage will occur.

Image density sensor assembly removal

1. Remove the printer front door assembly. See
2. Remove the front left cover. See
3. Remove the waste toner cartridge cover. See
4. Remove the waste toner cartridge sensor assembly. See
on page 4-39.
5. Remove the inner cover. See
6. Remove the waste toner agitator motor assembly. See
page 4-44.
7. Remove the screw securing the harness access cover (A) to the machine.
Button
B
"Printer front door assembly removal" on page
"Front left cover removal" on page
"Waste toner cartridge cover removal" on page
"Inner cover removal" on page
A
4-9.
"Waste toner cartridge sensor assembly removal"
4-43.
"Waste toner agitator motor assembly removal" on
7510
4-3.
4-39.
4-45
