Ccd Initialization (Lamp Off) Error; Scanner Communication Error - Lexmark X940e Service Manual

7510
Step
5
Perform a POR.
Does the error remain when the power is turned off/on?

845.02 CCD initialization (lamp off) error

Step
1 Check the connection of the scanner controller card
assembly.
Are the connectors of the scanner controller card assembly
connected properly?
2
Perform a POR.
Does the error remain when the power is turned off/on?
3 Perform a POR.
Does the error remain when the power is turned off/on again?

846.00 Scanner communication error

Step
1
Check the scanner interface cable assembly connection
between the RIP card assembly and the scanner unit
assembly.
Is the scanner interface cable assembly connected properly?
2
Check all connections of the scanner controller card assembly.
Are the connections of the scanner controller card assembly
connected properly?
2-126
Service Manual
Check
Check
Check
Yes
Replace the Problem solved.
scanner
controller card
assembly.
"Scanner
Go to
controller card
assembly
removal" on
page 4-123.
Yes
Go to step 2. Connect each
connector of the
scanner
controller card
assembly
properly.
Replace the Problem solved.
scanner
controller card
assembly.
Go to "Scanner
controller card
assembly
removal" on
page 4-123.
Replace the Problem solved.
scanner PS card
assembly.
"Scanner
Go to
PS card
assembly
removal" on
page 4-126.
Yes
Go to step 2. Replace the
connection.
Go to step 3. Connect each
connector of the
scanner
controller card
assembly
properly.
No
No
No
