Switch (Printer Front Door Interlock) Removal - Lexmark X940e Service Manual

7510
Replacement warning: When reinstalling the printhead shutter motor assembly (A), ensure that the plastic arm
is inserted into the printhead shutter (B).

Switch (printer front door interlock) removal

1. Remove the rear cover assembly. See
2. Remove the right cover assembly. See
3. Remove the top cover assembly. See
removal" on page
4. Remove the connector form the switch (printer front door interlock) (A).
5. Release the hooks securing the switch (printer front door interlock) (A) to the machine.
6. Remove the switch (printer front door interlock) (A) from the machine.
4-68
Service Manual
B
"Rear cover assembly removal" on page
"Right cover assembly removal" on page
"Top cover assembly removal" on page 4-4
4-5.
Connectors
A
4-5.
4-4.
or "Rear cover assembly
