956.02 RIP card assembly cooling fan failure

Step
1 Perform a POR.
Does the error occur when the power is turned off/on?
2 Turn the printer off for 60 seconds.
Does the error occur when the power is turned off/on again?
3 Checking the RIP card assembly cooling fan and heatsink
attachment.
Is the above fan attached properly?

956.03 RIP card assembly FPGA failure

Step
1 Perform a POR.
Does the error occur when the power is turned off/on?
2 Turn the printer off for 60 seconds.
Does the error occur when the power is turned off/on again?

980.00 Communication error with 1TM, 3TM, or TTM assembly

Step
1
Check the 1TM, 2TM or TTM controller card assembly
and the printer engine card assembly for proper
connection.
Is the above component properly connected?
Check
Check
Check
Yes
Go to step 2. Perform several
print tests.
If the problem
remains, go to
step 2.
Go to step 3. Problem solved.
Replace the RIP Reattach the RIP
card assembly. card assembly
cooling fan and
"RIP card
Go to
heatsink.
assembly
removal" on
page 4-73.
Yes
Go to step 2. Perform several
print tests.
If the problem
remains, go to
step 2.
Replace the RIP Problem solved.
card assembly.
Go to "RIP card
assembly
removal" on
page 4-73.
Yes
Go to step 2. Replace the
connection.
Diagnostic information
7510
No
No
No
2-177
