The MPF/transport drive motor is a stepper motor that drives the MPF unit assembly and media transport roll.

CMYK PC cartridge drive motor assembly

The CMYK PC cartridge drive motor assembly uses dual DC brushless motors that drive the four drums in the

four PC cartridges.

K drive motor

K developer/transport

drive motor assembly

MPF/transport

CMY drive motor

General information
