Switch (printer left door interlock) removal

1. Remove the rear cover assembly. See
Warning: Ensure that the rear left middle cover is removed before removing the rear left upper cover, or
damage will occur.
2. Remove the rear left middle cover. See
3. Remove the rear left upper cover. See
4. Remove the standard media exit shift assembly. See
page 4-17.
A
B
B
C
"Rear cover assembly removal" on page
"Rear left middle cover removal" on page
"Rear left upper cover removal" on page
"Standard media exit shift assembly removal" on
7510
4-5.
4-6.
4-7.
4-19
Repair information
