Lexmark X940e Service Manual page 745

Assembly 36: ADF feeder
Asm Part Units/
Index number mach
1 40X3884
2 40X2265
3 40X2266
4 40X2264
5 40X2267
6 40X2270
7 40X2269
8 40X2327
9 40X2383
10 40X2272
11 40X2256
12 40X2271
13 40X2273
Units/ kit
Description
or pkg
1 1 ADF left cover assembly (this comes assembled)
1 1 Registration motor cable assembly
1 1 ADF feed motor cable assembly
1 1 Document set/sheet through cable assembly
1 1 Left cover hinge retainer
1 1 Registration main drive belt
1 1 Stud screw
1 1 ADF feed motor assembly (this comes assembled)
1 1 ADF main feed assembly (this comes assembled)
1 1 Document set LED
1 1 Inverter lever
1 1 Inverter solenoid assembly
1 1 Separation roll guide assembly (this comes assembled)
7510
7-43
Parts catalog
