Assembly 17: Duplex 2
Asm-
Part
FRUs/
index
number
mach
1
40X3799
2
40X3802
3
40X3801
4
40X3800
5
40X3803
5
4
Units/
Description
FRU
1
1
Duplex unit assembly (this comes assembled)
1
1
Duplex drive motor
1
1
Sensor (duplex wait)
1
1
Duplex controller card assembly
1
1
Switch (duplex left door interlock)
1
3
7510
2
7-19
Parts catalog
