Lexmark™ X94x

Quick Reference

Loading paper and
specialty media
Loading the 520-sheet trays
The printer has a standard 520-sheet tray (Tray 1), and it may have
one or more optional 520-sheet trays. All 520-sheet trays support
the same paper sizes and types. Paper may be loaded in the trays
in either the long-edge or short-edge orientation.
1
Grasp the handle, and pull the tray out.
2
Squeeze the width guide tabs together as shown, and move
the width guide to the correct position for the paper size being
loaded.
3
Squeeze the length guide tab inward as shown, and slide the
guide to the correct position for the paper size being loaded.
Note: Use the size indicators on the bottom of the tray to help
position the guides.
1
4
Flex the sheets back and forth to loosen them, and then fan
them. Do not fold or crease the paper. Straighten the edges on
a level surface.
5
Load the paper stack with the recommended print side faceup.
Load the paper in either the long-edge or short-edge
orientation as shown below:
Notes:
•
Load sizes larger than A4 in the short-edge orientation.
•
Paper must be loaded in the short-edge orientation to
create booklets if the optional booklet finisher is installed.
6
Make sure the paper guides are secure against the edges of
the paper.
7
Align the tray, and insert it.
8
If a different type of paper was loaded than the type previously
loaded in the tray, change the Paper Type setting for the tray
from the control panel.
