201.00 Sensor (fuser exit) late jam

Step
1 Check the media position.
Does the media touch the sensor (fuser exit)?
2 Check the fuser exit actuator.
Does the fuser exit actuator attached to the sensor (fuser
exit) appear to be binding or sticking in its normal resting
position and not allowing media to pass?
3 Check the 2nd transfer roll assembly.
Is the 2nd transfer roll assembly free of excess wear and
contamination?
4
Check the sensor (fuser exit) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch BASE SENSOR TEST.
3. Touch Media Path.
4. Touch Fuser exit.
Caution: The area around the actuator is very hot. Allow
the fuser area to cool before proceeding.
Does the display on the operator panel change every time
the sensing area of the above sensor is interrupted or
blocked?
5 Check the sensor (fuser exit) for proper connection.
Is the above component properly connected?
6 Check the duplex diverter gate solenoid for proper
operation.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Printer Motor Test.
4. Touch Duplex diverter gate solenoid.
Does the above component operate properly?
2-44
Service Manual
Check
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
Yes
Remove the Go to step 2.
media.
Replace the Go to step 3.
sensor (fuser exit)
Go to "Sensor
(fuser exit)
removal" on
page 4-25.
Go to step 4. Clean or replace
the 2nd transfer
roll assembly.
Go to
transfer roll
assembly
removal" on
page
Go to step 6. Go to step 5.
Replace the Replace the
sensor (fuser exit). connection.
Go to "Sensor
(fuser exit)
removal" on
page 4-25.
Go to step 8. Go to step 7.
No
"2nd
4-35.
