7. Remove the switch (transfer belt access door interlock) (A).

Laser diode power card assembly removal

1. Remove the rear cover assembly. See
2. Remove the rear upper cooling fan bracket assembly. See
removal" on page
3. Remove the developer / transfer roll HVPS card assembly. See
assembly removal" on page
4. Remove the lower printer engine card bracket assembly. See
removal" on page
5. Disconnect the connector from the laser diode power card assembly (A).
6. Release the four plastic supports with needle nose pliers.
"Rear cover assembly removal" on page
4-102.
4-103.
4-79.
Connector
A
"Rear upper cooling fan bracket assembly
"Developer / transfer roll HVPS card
"Lower printer engine card bracket assembly
7510
4-5.
4-83
Repair information
