Media Size Mismatch In Width - Lexmark X940e Service Manual

7510

Media size mismatch in width

Step
1 Check the media.
Is media properly loaded in the tray?
2 Check the media.
Is the rear media tray guide, and media tray end guide of tray
1 or tray 2 set correctly?
3
Check the switch (media size) for proper installation.
Pull out the media tray to visually check it.
Is the switch (media size) for media tray 1 and media tray 2
installed correctly?
4
Check the switch (media size) connection for tray 1 and/or
tray 2.
Is the switch (media size) properly connected for tray 1 and/or
tray 2?
5 Perform a print test.
Does the error continue when the power is turned off/on?
Media size mismatch in width
Step
1 Check the media.
Pull out the tray, and visually check it.
Is the media loaded in tray properly?
2 Check the media.
Pull out the tray, and visually check it.
Are the front media guide and rear media guide on
tray 3 or tray 4 set correctly?
3 Check the switch (TTM media size) for proper
installation.
Pull out the tray, and visually check it.
Is the switch (TTM media size) for tray 3 or tray 4
installed properly?
2-182
Service Manual
Check
Check
Yes
Go to step 2. Load media
properly.
Go to step 3. Set the guides
properly.
Go to step 4. Install the switch
(media size) for
each media tray
correctly.
Replace the Replace the
required switch connection.
(media size).
Go to "Switch
(media size)
removal" on
page 4-114.
Replace the Problem solved.
upper printer
engine card
assembly.
Go to "Upper
printer engine
card assembly
removal" on
page 4-77.
Yes
Go to step 2. Load media
properly.
Go to step 3. Set the parts
correctly.
Go to step 4. Install the switch
(TTM media size)
correctly.
Go to
dual input
(TTM)–switch
(TTM media size)
removal" on
page
No
No
"2000-sheet
4-182.
