Tray 3 Media Size Mismatch Error; Tray 4 Media Size Mismatch Error - Lexmark X940e Service Manual

7510

Tray 3 media size mismatch error

Step
1 Check the media tray assembly 3 side guide.
Is the above component set properly?
2
Check the media tray assembly 3 end guide.
Is the above component set properly?
3 Check the media tray assembly for damage.
Is the above component damaged?
4
Check the switch (media size) for proper connection.
Is the above component properly connected?
5 Perform a POR.
Does the error remain when the power is turned off/on?
6 Perform a POR.
Does the error remain when the power is turned off/on
again?

Tray 4 media size mismatch error

Step
1
Check the media tray assembly 4 side guide.
Is the above component set properly?
2 Check the media tray assembly 4 end guide.
Is the above component set properly?
3 Check the media tray assembly for damage.
Is the above component damaged?
4
Check the switch (media size) for proper connection.
Is the above component properly connected?
2-202
Service Manual
Check
Check
Yes
Go to step 2. Properly set the
media tray
assembly side
guide.
Go to step 3. Properly set the
media tray
assembly end
guide.
Replace the media Go to step 4.
tray assembly.
Replace the switch Replace the
(media size) connection.
Replace the upper Problem solved.
printer engine card
assembly.
Go to "Upper
printer engine
card assembly
removal" on
page 4-77.
Replace the RIP Problem solved.
card assembly.
Go to "RIP card
assembly
removal" on
page 4-73.
Yes
Go to step 2. Properly set the
media tray
assembly side
guide.
Go to step 3. Properly set the
media tray
assembly end
guide.
Replace the media Go to step 4.
tray assembly.
Replace the switch Replace the
(media size) connection.
No
No
