903.02 CMY PC drive motor error

Step
1 Perform a POR.
Does the error occur when the power is turned off/on?
2
Check the CMYK PC cartridge drive motor assembly for
proper operation.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Printer Motor Tests
4. Touch CMY cartridge drive motor
Does the above component operate properly?
3
Check the CMYK PC cartridge drive motor assembly for
proper connection.
Is the above component properly connected?
4
Perform a POR.
Does the error occur when the power is turned off/on?

903.03 Developer drive motor error

Step
1
Perform a POR.
Does the error occur when the power is turned off/on?
2-142
Service Manual
Check
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
Check
Yes
Go to step 2. Perform several
print tests.
If the problem
remains, go to
step 2.
Go to step 4. Go to step 3.
Replace the Replace the
CMYK PC connection.
cartridge drive
motor assembly.
"CMYK PC
Go to
cartridge drive
motor assembly
removal" on
page 4-91.
Replace the lower Problem solved.
printer engine card
assembly.
"Lower
Go to
printer engine
card assembly
removal" on
page 4-80.
Yes
Go to step 2. Perform several
print tests.
If the problem
remains, go to
step 2.
No
No
