Sensor (Adf Width Aps1), Sensor (Adf Width Aps 2) And Sensor (Adf Width Aps 3) Static - Lexmark X940e Service Manual

Step
15 Place an undamaged document in the ADF, and perform
a ADF test.
Does the error remain?
290.20 Sensor (ADF width APS1), sensor (ADF width APS 2) and sensor (ADF width
APS 3) static jam
Step
1 Check the document size.
Is the correct size document being inserted into the ADF?
2 Check the connection of each ADF controller card assembly
connector.
Is each connector of ADF controller card assembly
connected properly?
3 Check the sensor (ADF width APS 1) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch ADF width APS 1.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
4 Check the sensor (ADF width APS 1) for proper connection.
Is the above component properly connected?
5
Check the sensor (ADF width APS 2) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch ADF width APS 2.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
6
Check the sensor (ADF width APS 2) for proper connection.
Is the above component properly connected?
Check
Check
Yes
Replace the Problem solved.
RIP card
assembly.
Go to "RIP
card assembly
removal" on
page 4-73.
Yes
Go to step 2. Insert the proper
size document into
the ADF.
Go to step 3. Connect each
connector of ADF
controller card
assembly properly.
Go to step 5. Go to step 4.
Replace the Replace the
sensor (ADF width connection.
APS 1).
Go to "Sensor
(ADF width APS
1) removal" on
page 4-146.
Go to step 7. Go to step 6.
Replace the Replace the
sensor (ADF width connection.
APS 2).
Go to "Sensor
(ADF width APS
2) removal" on
page 4-147.
Diagnostic information
7510
No
No
2-85
