2000-sheet dual input (TTM)—media out actuator removal
1. Remove the tray module left cover. See
page 4-167.
2. Remove the TTM media tray 3 assembly. See
removal" on page
3. Remove the TTM media tray 4 assembly. See
removal" on page
4. Remove the tray 4 media transport assembly. See
assembly removal" on page
5. Remove the media feed unit assembly. See
removal" on page
page 4-183, or
6. Release the two bosses on the media out actuator (A) from the media feed unit assembly.
7. Remove the media out actuator (A).
4-190
Service Manual
"2000-sheet dual input (TTM)– tray module left cover removal" on
4-171.
4-170.
4-175.
4-183, "2000-sheet dual input (TTM)–media feed unit assembly removal (tray 3)" on
"2000-sheet dual input (TTM)–media feed unit assembly removal (tray 4)" on page
Bosses
"2000-sheet dual input (TTM)–TTM media tray 3 assembly
"2000-sheet dual input (TTM)–TTM media tray 4 assembly
"2000-sheet dual input (TTM)–TTM tray 4 media transport
"2000-sheet dual input (TTM)–media feed unit assembly 2
Front
A
Lower view
4-179.
