9.
Have someone help you lift the printer straight off the LFU
vertically until the printer is free of the alignment posts (fig.
10.3). Then set the printer on a stable surface that will support
its weight.
Warning!
The printer weighs approximately 101 lbs (46 kg)
without toner, cassettes, and media installed. Always
have two people lift the printer by the recessed grip
areas on the bottom sides.
10.
Close the LFU metal coupler 2 (fig. 10.2) and lay the LFU
cable back up on the LFU in the sloped area where it comes
out to prevent damage when the unit is stored. (fig. 10.1).
11.
Repack the LFU in its original packing materials, making sure
to include the 2 side covers, metal coupler 1, and the paper
cassette. Then, store it in a location that meets the same
guidelines as in "Storing the Printer" in chapter 9.
12.
Set the printer up again following the instructions in chapter 2.
Also be sure to reinstall the LFU Connector cover (fig. 10.5).
Duplexer
This section describes installing and removing the optional duplexer.
Installing the Duplexer
You must have at least one optional LFU (Lower Feeder Unit)
installed on the printer before installing the duplexer.
Tools required: Small flat head screw driver
1.
Unpack the duplexer from its shipping carton. Remove all
plastic, tape, and stabilizing materials. Save the carton and
packing materials to use for storing the duplexer.
2.
Place the duplexer close to the printer in an area that meets the
guidelines in "Printer Location" in chapter 2.
___________________________________________
Options 10-13
