Goodrive3000 series medium voltage VFD
P16 group––Ethernet function
Function
Name
code
Ethernet
P16.00 communication
speed setting
The function code is used for Ethernet communication speed setting. Generally, select the default value.
Function
Name
code
P16.01 IP address 1
P16.02 IP address 2
P16.03 IP address 3
P16.04 IP address 4
P16.05 Subnet mask 1
P16.06 Subnet mask 2
P16.07 Subnet mask 3
P16.08 Subnet mask 4
The function codes are used to set the IP addresses and subnet masks for Ethernet communication.
IP address format: P16.01. P16.02. P16.03. P16.04
Subnet mask format: P16.05. P16.06. P16.07. P16.08
Function
Name
code
P16.09 Gateway 1
P16.10 Gateway 2
P16.11 Gateway 3
P16.12 Gateway 4
Set the gateway for Ethernet communication.
Description
0: Self-adapting
1: 100M full-duplex
2: 100M half-duplex
3: 10M full-duplex
4: 10M half-duplex
Description
0–255
0–255
0–255
0–255
0–255
0–255
0–255
0–255
For example: IP address is 192.168.0.1.
For example: Subnet mask is 255.255.255.0.
Description
0–255
0–255
0–255
0–255
-170-
Goodrive3000 inverter
Setting range Default
0–4 3
Setting range Default
0–255 192
0–255 168
0–255 0
0–255 1
0–255 255
0–255 255
0–255 255
0–255 0
Setting range Default
0–255 192
0–255 168
0–255 1
0–255 1
