P20--Encoder Of Motor 1 - INVT Goodrive350 Series Operation Manual

Goodrive350 series high-performance multifunction VFD
Function
Name
code
Software version
P19.03 of the extension
card in card slot 1
Software version
P19.04 of the extension
card in card slot 2
Software version
P19.05 of the extension
card in card slot 3
Input state of
P19.06 extension I/O
card terminals
Output state of
P19.07 extension I/O
card terminals
HDI3 input
frequency of
P19.08
extension I/O
card
AI3 input voltage
P19.09 of extension I/O
card
P19.10–
Reserved
P19.39
P20––Encoder of motor 1
Function
Name
code
Encoder type
P20.00
display
Encoder pulse
P20.01
number
Description
16: Modbus communication card
17: EtherCAT communication card
18: BacNet communication card
19: DeviceNet communication card
0.00–655.35
0.00–655.35
0.00–655.35
0–0xFFFF
0–0xFFFF
0.000–50.000kHz
0.00–10.00V
0–65535
Description
0: Incremental encoder
1: Resolver-type encoder
2: Sin/Cos encoder
3: Endat absolute encoder
Number of pulses generated when the encoder
revolves for one circle.
Setting range: 0–60000
-212-
Function parameter list
Default
Modify
value
●
0.00
●
0.00
●
0.00
●
0
●
0
0.000
●
kHz
●
0.00V
●
0
Default
Modify
value
●
0
◎
1024
