Goodrive350 series high-performance multifunction VFD
Function
Name
code
mode for
asynchronous
motor 2
Starting
frequency point
for switching off
P04.49
IF mode for
asynchronous
motor 2
End frequency
point for
switching off IF
P04.50
mode for
asynchronous
motor 1
End frequency
point for
switching off IF
P04.51
mode for
asynchronous
motor 2
P05––Input terminals
Function
Name
code
P05.00 HDI input type
Function of S1
P05.01
terminal
Function of S2
P05.02
terminal
Function of S3
P05.03
terminal
P05.04 Function of S4
Description
coefficient of the output current closed-loop
control.
Setting range: 0–5000
0.00–P04.51
P04.44–P00.03
P04.49–P00.03
Description
0x00–0x11
Ones: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0: No function
1: Forward running
2: Reverse running
3: 3-wire control/Sin
4: Forward jogging
5: Reverse jogging
6: Coast to stop
-156-
Function parameter list
Default
Modify
value
○
10.00Hz
○
25.00Hz
○
25.00Hz
Default
Modify
value
◎
0
◎
1
◎
4
◎
7
◎
0
