set {ap | dap} radio
auto-tune
max-power
antennatype
{ANT-1360-OUT | ANT5360-OUT | ANT5060 | ANT5120-OUT |
— 802.11a external antenna models:
internal}
ANT1360-OUT
ANT5360-OUT
ANT5060-OUT
ANT5120-OUT
— uses the internal antenna instead
internal
Defaults — All radios use the internal antenna by default, if the MAP
model has an internal antenna. The MP-620 802.11b/g radio uses model
ANT-1360-OUT by default. The MP-620 802.11a radio uses model
ANT-5360-OUT by default. The MP-262 802.11b/g radio uses model
ANT1060 by default.)
Access — Enabled.
History — Introduced in MSS Version 3.0. Model numbers added for
802.11a external antennas, and the default changed to internal (except
for the MP-262) in MSS Version 3.2. Model numbers added for MP-620
external antennas.
Examples — The following command configures the 802.11b/g radio on
Distributed MAP 1 to use antenna model ANT1060:
WX4400# set dap 1 radio 1 antennatype ANT1060
success: change accepted.
See Also
display {ap | dap} config on page 290
Sets the maximum power that RF Auto-Tuning can set on a radio.
Syntax — set {ap port-list | dap dap-num
auto-tune max-power power-level
ap port-list — List of ports connected to the MAP access points on
which to set the channel.
dap dap-num — Number of a Distributed MAP on which to set the
channel.

set {ap | dap} radio auto-tune max-power

— 360° 802.11b/g antenna
— 360° 802.11a antenna
— 60° 802.11a antenna
— 120° 802.11a antenna
335
| auto} radio {1 | 2}
